Komar’s under-60″ vertical balers deliver high performance in compact spaces, offering dependable, space-efficient solutions for facilities with low recycling volumes or specialized material handling needs. Built with the same rugged construction and safety standards as our larger models, these units excel in retail, office, hospitality, and light industrial environments where footprint and efficiency must coexist.
This category also includes specialty balers designed for unique challenges—such as liquid extraction balers and drum crushers for safe, efficient disposal. Each solution is engineered for daily use, transforming limited space into productive recycling capacity—helping organizations reduce waste, maintain cleaner work areas, and uphold responsible waste-handling practices.
Quickly flattens 55-gallon steel drums. Makes it look easy.
Materials weighed down with liquids? Not after these machines are finished.
Got more cardboard and recyclables than you have space? Look no further.
Designed for tight spaces without sacrificing performance.
Heavy-gauge steel frames built to last in commercial environments.
Intuitive controls and simplified maintenance keep downtime to a minimum.
Meets OSHA and ANSI standards with interlocked access panels, emergency stop systems, and UL-Listed electrical components for added assurance.
Compact hydraulic systems reduce noise and energy use.
Select models include forklift pockets or optional mobility features for easier placement.
Note: Options may not be available for all models.
“We went from paying $18,000 to $20,000 a year for plastic removal by a local waste company to selling our compacted bales to our pots and tray manufacturers for $8,000 to $10,000 per year! So… we paid for our baler in less than a year! Every time the baler runs, it sounds just like printing money. Thanks for delivering a great product and one that does exactly what you said it would! Very refreshing to deal with an honorable company.”
John Hardiman, American Farm
Compact vertical balers help facilities manage moderate material flow without sacrificing floor space. They streamline recycling, reduce handling inefficiencies, and support compliance and sustainability and goals.
| Vertical Balers |  V36 | V42 |  V48 |
|---|---|---|---|
| Overall (WxDxH) | 47.25″×29.5″×95.75″ | 50″×28″×86″ | 61″×38.25″×138″ |
| Feed Height | 32.75″ | 35″ | 46.25″ |
| Bale Weight (OCC) | 100 – 250 Lbs | 300 Lbs | 400 – 600 Lbs |
| Bale Width | 36″ | 42″ | 48″ |
| Bale Depth | 24″ | 24″ | 30″ |
| Bale Height | 30″ | 30″ | 36″ |
| No. of Bale Tie Slots | 3 | 4 | 4 |
| Pump | 3.2 GPM | 2.8 GPM | 10.5 GPM |
| Control Voltage | 110 – 120 Vac | 110 – 120 Vac | 110 – 120 Vac |
| Voltage, 3-phase | 208/230/480V | 208/230/480V | 208/230/480V |
| Ship Weight | 1,350 Lbs | 1,750 Lbs | 3,500 Lbs |
| Cylinder Bore | 4″ | 3″ | 6″ |
| Cylinder Rod | 2.5″ | 1.5″ | 3.5″ |
| Rod Stroke | 32″ | 30″ | 48″ |
| Motor | 3 Hp | 3 Hp | 10 Hp |
| Ejection System | Semi-Automatic | Semi-Automatic | Semi-Automatic |
| Hydraulic Tank Capacity Gallons | 10 | 10 | 22 |
| Average Cycle Time | 39 sec | 43 sec | 56 sec |
| Working Pressure | 1,600 psi | 1,700 psi | 1,700 psi |
| Relief Pressure | 1,900 psi | 2,100 psi | 2,000 psi |
| Working Force | 20,100 lbs | 12,016 lbs | 48,057 lbs |
| Relief Force | 23,870 lbs | 14,843 lbs | 56,538 lbs |
| Normal Ram Pressure | 23.6 psi | 11.9 psi | 35.0 psi |
| Max Ram Pressure | 28.0 psi | 13.7 psi | 41.2 psi |
| Overall (WxDxH) | 57″ × 37″ × 113″ |
| Bale Depth | N/A |
| Drum Output Size | 4″–6″ |
| Pump | 10.5 GPM |
| Control Voltage | 110 – 120 Vac |
| Voltage, 3-phase | 208/230/480V |
| Ship Weight | 3,500 lbs |
| Cylinder Bore | 6″ |
| Cylinder Rod | 2″ |
| Rod Stroke | 43″ |
| Motor | 10 Hp |
| Ejection System | Manual |
| Hydraulic Tank Capacity (Gallons) | 22 |
| Average Cycle Time | 48 sec |
| Working Pressure | 2,000 psi |
| Maximum Pressure | 2,200 psi |
| Working Force | 56,548 lbs |
| Relief Force | 62,202 lbs |
| Normal Ram Pressure | 117 psi |
| Max Ram Pressure | 44 psi |
| Overall (W×D×H) | 70″ × 43″ × 130″ |
| Feed Height | 42″ |
| Bale Weight (OCC) | Up to 250 lbs |
| Bale Width | 30″ |
| Bale Depth | 16″ |
| Bale Height | 24″ |
| No. of Bale Tie Slots | 4 |
| Pump | 12 GPM |
| Control Voltage | 110 – 120 Vac |
| Voltage, 3-phase | 208/230/480V |
| Ship Weight | 3,800 lbs |
| Cylinder Bore | 6″ |
| Cylinder Rod | 3.5″ |
| Rod Stroke | 48″ |
| Motor | 15 HP |
| Ejection System | Semi-Automatic |
| Hydraulic Tank Capacity (Gallons) | 22 |
| Average Cycle Time | 49 seconds |
| Working Pressure | 2,200 psi |
| Relief Pressure | 2,400 |
| Working Force | 62,203 lbs |
| Relief Force | 67,858 |
| Normal Ram Pressure | 98 psi |
| Max Ram Pressure | 108 psi |
Our solutions are tailored to meet the unique needs of a wide range of industries including:
Compact balers are ideal for tight spaces such as retail back rooms, small warehouses, restaurants, or facilities with low ceilings where full-size units will not fit. They provide strong material handling and volume reduction without requiring a large footprint.
Depending on the model and material, compact balers can produce bales ranging from 50 lbs up to 600 lbs. Smaller units handle light streams weighing in the 50-200 lb range, while heavy-duty compact models can create bales weighing 400–600 lbs.
Yes. They include enclosed chambers, interlocked panels, automatic shutoffs, emergency stop buttons, and UL-listed components. With proper training, risk is minimal even in active environments.
Select models feature forklift pockets or optional casters, making relocation simple for seasonal layout changes or variable production needs.
Training is minimal. A general safety and operation overview is all that is required. Every Komar system includes manuals to ensure proper procedures are followed.
Compact bales are easy to handle with hand carts or pallet jacks and can be staged for pickup by local recycling services or near dock doors for collection.
Yes. Many businesses start with compact balers and upgrade as needs grow. Komar offers scalable solutions to plan for future capacity.
We are a waste solutions company. With a wide array of application-specific models and advanced engineering capabilities, we look forward to guiding you to the best solution for the job.
Schedule a free waste stream evaluation to identify the right equipment and processes for your space, waste types, and volume.
Compact vertical balers help facilities manage moderate material flow without sacrificing floor space. They streamline recycling, reduce handling inefficiencies, and support compliance and sustainability and goals.
Why Choose a Compact Vertical Baler
Under-60″ balers are ideal when:
These balers provide efficient compaction, organized bale output, and a manageable workflow for smaller teams.
Key Advantages
Expert Insight:
Selecting the right baler size prevents overinvestment and ensures operational efficiency. A compact baler is often the smartest entry point for businesses improving recycling without disrupting workflows.
