Ordinary machines can’t keep pace with constant streams of cardboard and wood. High-volume operations require faster intake and continuous processing that standard systems weren’t built to handle. That’s where Komar dual compaction augers come in.
Powerful, high-efficiency equipment made to handle high volume cardboard and wood streams.
20 HP
Displacement Rate
3.5 ton/hr
Tons/40 yd Container
Chamber Size (LxW)
60 HP
Displacement Rate
6-12 yd³/min
Tons/Trailer
15-20 tons (w/walking floor assist)
Chamber Size (LxW)
120 HP
Displacement Rate
8.5-17 yd³/min
Tons / Trailer
15-20 tons (w/walking floor assist)
Chamber Size (LxW)
Material volumes that would cause ordinary machines to choke are no match for these machines.
“We estimate that the Komar Auger has saved us 1,300 hours of labor per year, has reduced our hauling cost by two-thirds, and has given La-Z-Boy a safer process and more floor space.”
Troy Kvingedal, Facilities Supervisor, La-Z-Boy
“Our facility is a 110,000-square-foot operations center for Goodwill of Southwestern Pennsylvania. We get between 1.2 to 1.5 million pounds of material a day, and tonnage increases significantly during the summer. The Komar auger has increased daily soft trash, wood pallets, and general trash efficiency by 30% and 40% with furniture. I love to give shock-and-awe tours to show off the Komar Auger, which compacts 8.5 to 9 tons into each payload.”
Bob Kagle, Director of Retail Logistics, Goodwill of Southwestern Pennsylvania
“Since installing our Komar Auger, we have improved our operations tremendously. The auger units have reduced labor from six people down to one person, who oversees the conveyor lines and compactors. We have gone from a 2-ton payload to a 10-ton-plus payload, per 40-yard container, reducing our annual pull charges by over 75%. We have less downtime and have eliminated jams due to the slow operation of the old compactors. Best of all, we had less than a one-year return on investment.”
John Hefty, Operations Manager, GameStop
When waste volume rises and material flow becomes overwhelming, the most effective path is often the simplest: Dual Compaction Augers. Komar’s dual-screw systems harness decades of engineering knowledge to deliver high-capacity, smooth material flow, and optimized compaction for the toughest industrial waste streams.
Our solutions are tailored to meet the needs of a wide range of industries, including:
| Horsepower Auger 1 | 20 |
| Horsepower Auger 2 | 20 |
| Drive Type | Electro-Mechanical |
| Power Requirement | 480 V, 3 PH, 60 Hz |
| Overcurrent Protection (MCP-type Breaker) | 70 amp |
| Auger 1 Speed | 9.6 RPM |
| Auger 2 Speed | 9.6 RPM |
| Auger 1 Torque | 10,966 ft-lbs |
| Auger 2 Torque | 10,966 ft-lbs |
| Auger Type | Straight |
| Auger 1 Diameter | 28” |
| Auger 2 Diameter | 28” |
| Displacement Rate | 3.5 ton/hr |
| Container Fill (40 Yd) | 8–10 tons |
| Chamber Opening (LxW) | 64” x 84” |
| Full System Weight (Includes Hopper) | 15,000 lbs |
| Feed Methods | Hand, Forklift, Tipper, Conveyor, Chute |
| Feed Materials | Cardboard (OCC) |
| Horsepower Auger 1 | 60 |
| Horsepower Auger 2 | 60 |
| Drive Type | Electro-Mechanical |
| Power Requirement | 480 V, 3 PH, 60 Hz |
| Overcurrent Protection (MCP-type Breaker) | 200 amp |
| Auger 1 Speed | 16.3 RPM |
| Auger 2 Speed | 16.3 RPM |
| Auger 1 Torque | 19,350 ft-lbs |
| Auger 2 Torque | 19,350 ft-lbs |
| Auger Type | Straight |
| Auger 1 Diameter | 34″ |
| Auger 2 Diameter | 34″ |
| Displacement Rate | 6–12 yd³/min |
| Pallet Size (LxW) – Standard | 72″ x 48″ |
| Pallet Size (LxW) – Special Configuration & Handling Required | 72″ x 48″ |
| Crate Size (LxWxH) – Standard | 60″ x 48″ x 48″ |
| Crate Size (LxWxH) – Special Configuration & Handling Required | 60″ x 48″ x 48″ |
| Spool Size (dia.) – Standard | 36″ |
| Spool Size (dia.) – Special Configuration & Handling Required | 36″ |
| Container Fill (Trailer) | 15-20 tons (with walking floor assist) |
| Chamber Opening (L x W) | 80″ x 80″ |
| Full System Weight (Includes Hopper) | 38,900 lbs |
| Feed Methods | Hand, Forklift, Tipper, Conveyor |
| Feed Materials | Cardboard (OCC), Wood – Pallets and Crates, MSW |
| Horsepower Auger 1 | 120 |
| Horsepower Auger 2 | 120 |
| Drive Type | Electro-Mechanical |
| Power Requirement | 480 V, 3 PH, 60 Hz |
| Overcurrent Protection (MCP-type Breaker) | 400 amp |
| Auger 1 Speed | 22.6 RPM |
| Auger 2 Speed | 22.6 RPM |
| Auger 1 Torque | 22,850 ft-lbs |
| Auger 2 Torque | 22,850 ft-lbs |
| Auger Type | Straight |
| Auger 1 Diameter | 34” |
| Auger 2 Diameter | 34” |
| Displacement Rate | 8.5–17 yd³/min |
| Pallet Size (LxW) – Standard | 72” x 48” |
| Pallet Size (LxW) – Special Configuration & Handling Required | 72” x 48” |
| Crate Size (LxWxH) – Standard | 60” x 48” x 48” |
| Crate Size (LxWxH) – Special Configuration & Handling Required | 60” x 48” x 48” |
| Spool Size (dia.) – Standard | 36” |
| Spool Size (dia.) – Special Configuration & Handling Required | 36” |
| Container Fill (Trailer) | 15–20 tons |
| Chamber Opening (L x W) | 80” x 80” |
| Full System Weight (Includes Hopper) | 43,900 lbs |
| Feed Methods | Hand, Forklift, Tipper, Conveyor, Chute |
| Feed Materials | Cardboard (OCC), Wood – Pallets and Crates, MSW |
Dual compaction augers are designed to process cardboard, wood pallets, crates, and municipal solid waste (MSW), making it suitable for high-volume, high-speed operations.
Two augers feed and pre-shred material simultaneously, reducing bridging and particle size, which maximizes compaction and container fill rates.
Thanks to precision machining, sealed bearings, and an automatic lubrication system, routine maintenance is minimal and focused on inspection rather than frequent service. Komar also offers Preventative Maintenance programs to help keep equipment operating reliably over the long term.
Yes. The system is designed for heavy-duty, continuous operation and can handle large quantities of cardboard and wood without frequent downtime.
Open top hoppers for flexible top-loading and plug-In hoppers for dock door integration.
The system is powered by an electro-mechanical drives, typically operating on 480 V, 3PH, 60 Hz with overcurrent protection via MCP-type breakers. Each unit can be configured with other options and comes with a custom-designed control panel, set to optimize the equipment performance and up-time.
We are a waste solutions company. With a wide array of application-specific models and advanced engineering capabilities, we look forward to guiding you to the best solution for the job.
Schedule a free waste stream evaluation to identify the right equipment and processes for your space, waste types, and volume.
When waste volume surges and material flow becomes overwhelming, the most effective solution is often the simplest: Dual Compaction Augers. These systems apply proven engineering principles to deliver high-capacity performance, smooth material flow, and optimized compaction for demanding industrial waste streams.
Dual auger systems use two synchronized screws that draw in material, break it down, and move it forward with controlled force. They are best suited for:
This design minimizes bridging, balances surge loads, and maintains consistent throughput even when material is irregular or heavy.
Two screws provide more bite and pressure, creating smoother flow and superior handling of tough materials that resist single-screw systems.
The synchronized design produces heavier, denser loads that reduce hauling frequency and improve long-term cost efficiency.
Dual augers can move material more quickly and maintain consistent flow, even under surge loads. This speed advantage reduces bottlenecks and supports continuous-feed or high-volume operations.
Dual augers can operate with minimal operator involvement, increasing uptime and improving safety. When paired with automated feeding systems such as conveyors, they can function as a fully autonomous solution. Facilities that eliminate manual material breakdown and loading achieve true hands-off operation, maximizing efficiency and reducing labor requirements.
Frames are reinforced, flighting is heavy-duty, and shafts are engineered for durability. Reliability is not an upgrade; it is the foundation.
While dual compaction augers typically represent a significant capital investment, the payback can be rapid and substantial when systems are applied correctly. Higher compaction density reduces hauling frequency, automation minimizes labor costs, and durability lowers maintenance expenses. Over time, these factors combine to deliver measurable savings and long-term operational efficiency.
Select dual compaction augers when:
In demanding environments, dual augers provide the most reliable, efficient, and long-term solution.
